Multi-tube Blowing Microduct fiber optic cable
Multi-tube Blowing Microduct Cable is an outdoor micromodule fibre optic cable used for telecommunication networks, CATV and FTTH (Fibre to the Home). We offer a wide range of indoor and outdoor fibre optic distribution, patching and consumer cables including Plenum, Riser and LSZH in all diameters. The Microduct Airblown Cable 144F is used to provide links to protocols such as FTTH, FDDI, 10 Gigabit Ethernet, ATM.
Share:
● Telecommunication networks
● CATV – Cable television
● Fibre-To-The-Home (FTTH)
Characteristics
● 2-144 FO
● Outer sheath (HDPE, Black)
● Multi loose-tube microduct
● Airblown
● Outdoor use
● Available in many colors
Dimensions
|
Standard Reel Length: 2000m; Other lengths available on request. |
Dimensions
|
Fiber count |
12~72 |
74~84 |
86~96 |
98~108 |
110~120 |
122~132 |
134~144 |
|
|
Max. cores in tube |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
|
|
Element number |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
|
|
Cable diameter(mm) |
5.8 |
6.2 |
6.7 |
7.3 |
7.8 |
8.3 |
8.7 |
|
|
Weightapprox. (kg/km) |
32 |
38 |
46 |
53 |
59 |
66 |
72 |
|
|
Duct size |
Ф10/Ф8 |
Ф10/Ф8 |
Ф12/Ф10 |
Ф12/Ф10 |
Ф12/Ф10 |
Ф12/Ф10 |
Ф12/Ф10 |
|
|
Tensile strength(N) |
Long term |
0.15*G (G- 1 km cable weight) |
||||||
|
Short term |
0.5*G (G- 1 km cable weight) |
|||||||
|
Crush Resistance(N/100mm) |
Long term |
150 |
||||||
|
Short term |
450 |
|||||||
|
Bending Radius(mm) |
Dynamic |
≥20×Cable Diameter |
||||||
|
Static |
≥10×Cable Diameter |
|||||||
|
Friction coefficient |
Dynamic |
0.15 |
||||||
|
Static |
0.25 |
|||||||
|
Operating Temperature(℃) |
-40 --- +60 |
|||||||
|
Minimum blowing length once time |
≥1000m within 30minutes |
|||||||
|
Application |
Duct |
|||||||
Dimensions
|
Fiber Type |
Attenuation |
OFL Bandwidth |
Effective mode bandwidth @850nm |
Ethernet link length |
Minimum bending radius |
||||
|
@850 nm |
@1300 nm |
@1310 nm |
@1550 nm |
@850 nm |
@1300 nm |
||||
|
G.657A1 |
-- |
-- |
≤0.36dB/km |
≤0.22dB/km |
-- |
-- |
-- |
-- |
10mm |
|
G.657A2 |
-- |
-- |
≤0.36dB/km |
≤0.22dB/km |
-- |
-- |
-- |
-- |
7.5mm |
|
OM3 |
≤3.0dB/km |
≤1.0dB/km |
-- |
≥1500MHz·km |
≥500MHz·km |
≥2000MHZ.km |
≤300m |
30mm |
|
|
OM4 |
≤3.0dB/km |
≤1.0dB/km |
-- |
≥3500MHz·km |
≥500MHz·km |
≥4700MHZ.km |
≤550m |
30mm |
|
Fiber Type
B1.3 = G652D OM3 = MaxBand*300
B6A1 = G657A1 OM4 = MaxBand*550
B6A2 = G657A2 BI-OM3 = MaxBand*300
A1 = 50/125μm BI-OM4 = MaxBand*550
A1b = 62.5/125μm
