Central Tube Optical Cable GYXTY/S/A

GYXTY/S/A cable use the fibers, 250µm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. Two parallel steel wires are placed at the two sides of the jacket.The cable is completed with a polyethylene (PE) sheath.

Dimensions(mm)

Fiber count			2~12	14~24
Tube diameter			Ф2.2	Ф3.2
Steel wire diameter(mm)/number			Ф0.7/12	Ф0.7/17
Max. cores in tube			12	24
Cable diameter（mm）		GYXTY	Ф7.5	Ф8.5
		GYXTS	Ф8.5	Ф9.5
		GYXTA	Ф8.5	Ф9.5
Cable weight（Kg/km）		GYXTY	77	105
		GYXTS	104	136
		GYXTA	91	120
Tensile strength（N）		Long term	600
		Short term	1500
Crush Resistance (N/100mm)		Long term	300
		Long term	1000
Bending Radius（mm）		Dynamic	≥20× cable diameter
		Static	≥10× cable diameter
Operating temperature(℃)			-40 --- +60
Application	GYXTY		Aerial, duct
	GYXTS		Aerial, duct, direct burial
	GYXTA		Aerial, duct, direct burial

Dimensions(mm)

Fiber Type	Attenuation				OFL Bandwidth		Effective mode bandwidth @850nm	Ethernet link length	Minimum bending radius
Fiber Type	@850 nm	@1300 nm	@1310 nm	@1550 nm	@850 nm	@1300 nm	Effective mode bandwidth @850nm	Ethernet link length	Minimum bending radius
G.657A1	--	--	≤0.36dB/km	≤0.22dB/km	--	--	--	--	10mm
G.657A2	--	--	≤0.36dB/km	≤0.22dB/km	--	--	--	--	7.5mm
OM3	≤3.0dB/km	≤1.0dB/km	--		≥1500MHz·km	≥500MHz·km	≥2000MHZ.km	≤300m	30mm
OM4	≤3.0dB/km	≤1.0dB/km	--		≥3500MHz·km	≥500MHz·km	≥4700MHZ.km	≤550m	30mm

Fiber Type

B1.3 = G652D OM3 = MaxBand*300

B6A1 = G657A1 OM4 = MaxBand*550

B6A2 = G657A2 BI-OM3 = MaxBand*300

A1 = 50/125μm BI-OM4 = MaxBand*550

A1b = 62.5/125μm
