Ribbon fiber optic cable GYDXTW

Ribbon fiber optic cable GYDXTW

ROC cable use fiber ribbon as optical communication medium. The wrapped with a layer of aramid yarn as strength member units, and the cable completed with PVC or LSZH material jacket.

Share:

● Adopted to indoor distribution.

● Interconnect between instruments and communication equipment.

● Ribbon Optical fibre jumper and pigtail.

Characteristics

● Aramid yarn as a strength member makes cable have excellent tensile strength.

● High-integrated fiber ribbon design.

● The outer jacket material has many advantages such as anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and harmless to the environment, etc.

Dimensions(mm)

Standard Reel Length: 2000m; Other lengths available on request.

Dimensions(mm)

 Fiber count

24~72

84~96

108~120

132~144

~216

~288

~432

~576

Fiber number per ribbon

12

12

12

12

12

24

24

24

Cable diameter approx (mm)

13.8

14.8

15.8

16.5

17.7

19.8

21.2

23.2

Weight approx  (Kg/km)

197

223

251

269

306

377

439

505

Tensile strength(N)

long term

600

short term

1500~3000

Crush resistance (N/100mm)

long term

300

short term

1000

Bending radius(mm)

dynamic

≥20× cable diameter

static

≥10× cable diameter

Operating temperature(℃)

-40--- +60

Application

Aerial, duct

Dimensions(mm)

Fiber Type

Attenuation

OFL Bandwidth

Effective mode bandwidth

@850nm

Ethernet link length

Minimum bending radius

@850 nm

@1300 nm

@1310 nm

@1550 nm

@850 nm

@1300 nm

G.657A1

--

--

≤0.36dB/km

≤0.22dB/km

--

--

--

--

10mm

G.657A2

--

--

≤0.36dB/km

≤0.22dB/km

--

--

--

--

7.5mm

OM3

≤3.0dB/km

≤1.0dB/km

--

≥1500MHz·km

≥500MHz·km

≥2000MHZ.km

≤300m

30mm

OM4

≤3.0dB/km

≤1.0dB/km

--

≥3500MHz·km

≥500MHz·km

≥4700MHZ.km

≤550m

30mm

Fiber Type

B1.3 = G652D  OM3 = MaxBand*300

B6A1 = G657A1  OM4 = MaxBand*550

B6A2 = G657A2  BI-OM3 = MaxBand*300

A1 = 50/125μm  BI-OM4 = MaxBand*550

A1b = 62.5/125μm
