Stranded Loose Tube Light-armored fiber optic cable GYTS

Home / Product / Outdoor Fiber Optic Cable / Stranded Loose Tube Light-armored fiber optic cable GYTS
Stranded Loose Tube Light-armored fiber optic cable GYTS

Stranded Loose Tube Light-armored fiber optic cable GYTS

The fibers, single-mode or multi-mode, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire, sometimes sheathed with polyethylene (PE) for cable with high fiber count, is located in the center of the core as a metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular cable core. The PSP is longitudinally applied over the cable core, which is filled with the filling compound to protect it from water ingress. The cable is completed with a PE sheath.

Share:

Characteristics

● Good mechanical and temperature performance.

● High-strength loose tube that is hydrolysis resistant.

● Special tube filling compound ensures the critical protection of fiber.

● Crush resistance and flexibility.

● PE sheath protects cable from ultraviolet radiation.

● The following measures are taken to ensure the cable is watertight:

Steel wire is used as the central strength member

Loose tube filling compound and 99.99% cable core ling

Aluminum tape enhances moisture-proof

Dimensions(mm)

Standard Reel Length: 2000m; Other lengths available on request.

Dimensions(mm)

Cable Type

(Increased by 2 fibers)

Fibre Count

Structure

Cable Weight Kg/Km (Ref)

Tensile Strength

Long/Short-Term(N)

Crush Resistance

Long/Short Term(N/10mm)

Bending Radius

Static/Dynamic(mm)

GYTS-2~30F

2~30

1+5

96

600/1500

300/1000

10D/20D

GYTS-32~72F

32~36

1+6

105

GYTS-74~84F

74~84

1+7

168

GYTS-86~96F

86~96

1+8

168

GYTS-98~108F

98~108

1+9

195

GYTS-110~120F

110~120

1+10

195

GYTS-122~132F

122~132

1+11

228

GYTS-134~144F

134~144

1+12

228

Storage/Operating Temperature: -40℃ to +70℃

Dimensions(mm)

Fiber Type

Numerical Aperture

Cable Cut-off Waverlength λcc

@850 nm

@1300 nm

@1310 nm

@1550 nm

@850 nm

@1300 nm

G.652

--

--

≤0.36dB/km

≤0.22dB/km

--

--

--

≤1260 nm

G.655

--

--

≤0.40dB/km

≤0.23dB/km

--

--

--

≤1450 nm

50/125 µm

≤3.0dB/km

≤1.0dB/km

--

≥500MHz·km

≥500MHz·km

0.200±0.015NA

--

625/125 µm

≤3.3dB/km

≤1.0dB/km

--

≥200MHz·km

≥500MHz·km

0.275±0.015NA

--
